MODA – Black Aluminium with Glass

Our Ecoscape aluminium balustrade system is available in black for a stylish finish to your commercial or domestic project. Ideal for outdoor or indoor spaces, the aluminium balustrade system is built to suit 10mm glass and provides a low-maintenance, durable solution with pre-assembled posts for quick and easy installation. Take a look at our Ecoscape Balustrade Brochure and Installation Guide for more information.
From From £225.00 Each
Download Brochure
Product Inspiration
Book A CPD

Specification

Price per Linear MeterFrom ÂĢ225 +VAT
(based on base fix post, cap, 10mm glass).
System Components Please refer to our Aluminium Balustrade System Component list.
ColourBlack – Other RAL Colours on request.
Product CodeECOAB______
MaterialAluminium
FinishPowder Coated
Post Length 1100mm (Base Fix) to 1395mm (Side Fix)
Post Width 50mm
Post Depth 50mm
Post Weight 2.7 / 4.6kg
Fixing MethodPlease see Installation guide.
Key FeaturesContemporary Slim 50x50mm Post, Pre-assembled posts ready to install, Modular System, Option of Base or Side Fix, Colour options. Fast Installation.

Useful Documents

Installation Guide
VIEW
Technical Sheets
VIEW
Technical Drawing (System):
VIEW

Technical Drawing (Components):

VIEW
Balustrade Brochure
VIEW
Architects Resources
VIEW
Warranty
VIEW

Features

  • Sleek 50x50mm fully assembled post
  • Modular System
  • To suit 10mm glass
  • Height with handrail 1125mm
  • Height without handrail 1095mm
  • Posts available in Base or Side Mounted fix
  • Rated to 0.74kN/m2
  • Tested to 1.2m post centres
  • Suitable for indoor and Outdoor
  • Gap between handrail and glass is 80mmBottom edge of glass to floor is 90mm
